Based in the vibrant industrial hub of Kolkata, Ram Aluminium has built a strong reputation for reliability and quality as a trusted manufacturer and supplier. We take pride in offering premium Aluminium 5005 Chequered Plates, a versatile solution known for its distinctive patterned surface that provides excellent slip resistance. Our commitment lies in delivering durable and high-performing materials that meet the rigorous demands of various industries, ensuring our clients receive products that combine strength with practicality for their most challenging projects right from the heart of India.
The Aluminium 5005 alloy strikes a wonderful balance, primarily composed of magnesium which gives it a notable boost in strength compared to other non-heat-treatable grades. This composition results in excellent corrosion resistance, making it highly suitable for demanding environments. Mechanically, these plates offer good formability and weldability, allowing for easy fabrication. The signature chequered pattern not only adds to its visual appeal but, more importantly, significantly enhances its anti-slip properties, contributing to safer workplaces and surfaces.
Standards : ASTM B209 / ASME SB209
Temper : O,H12,H14,H16,H18,H19,H22,H24,H26,H28,H32,H34,H36,H38
Thickness : 0.2-250
Width : 100-2600
Length : 500-10000
Surface : Bright, polished, hair line, brush, sand blast, embossed, etching, etc.
Finish :Mill, Customer specific finish
Aluminum Chequered Plate Coating : PVC Coated, Color Coated, Polyester, Fluorocarbon, polyurethane and epoxy coating
Type : Hot-Rolled (HR) / Cold-Rolled (CR) Chequered Plate
| UNS | DIN,WNr |
| A95005 | – |
| Material | Temper | Tensile Strength (N/mm²) | Yield Strength (N/mm²) | Elongation on 50mm (%) | |||
| 0.5 mm | 0.8 mm | 1.3 mm | 2.6mm | ||||
| 5005 | 0 | 95-145 | – | 18 | 20 | 21 | 22 |
| 5005 | H12 | 125-170 | 80 | 4 | 5 | 6 | 8 |
| 5005 | H14 | 145-185 | 100 | 3 | 3 | 5 | 6 |
| 5005 | H18 | 185 min | 165 | 1 | 2 | 3 | 3 |
Ram Aluminium based in Kolkata, India is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
Yes, we offer custom sizes for Aluminium 5005 Chequered Plates to meet specific project needs. Our team at Ram Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@ramaluminium.co.in
The unique combination of strength and slip-resistance makes these chequered plates incredibly useful across many fields. You’ll commonly find them underfoot in industrial settings, creating safe walkways on factory floors, stair treads, and loading docks. The transportation industry relies on them for truck floors and trailer beds, where durability is key. Their corrosion resistance also makes them a perfect choice for marine applications, such as ship decks and offshore platforms. Beyond industry, they are a popular, low-maintenance option for decorative panels and architectural features in modern construction.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
