Ram Aluminium stands out as a top-notch manufacturer and supplier of high-quality Aluminium 5005 coils in Kolkata, India. Renowned for its precision in manufacturing and unwavering quality, the company delivers coils that boast durability, corrosion resistance, and impressive formability. The Aluminium 5005 coils are crafted using cutting-edge rolling and finishing techniques, ensuring a consistent thickness, a smooth surface, and long-lasting performance. Catering to a variety of industries such as construction, roofing, transportation, and decorative applications, Ram Aluminium offers dependable solutions that align with industrial standards and meet specific customer needs, guaranteeing optimal performance in every project.
Aluminium 5005 is an aluminium-magnesium alloy, primarily made up of about 0.8–1.2% magnesium, along with trace amounts of manganese and silicon. This unique composition grants it excellent corrosion resistance, particularly in marine and outdoor settings. The coils exhibit commendable mechanical properties, including moderate strength, high ductility, and outstanding resistance to oxidation. They are highly workable, allowing for easy bending, forming, and rolling without the risk of cracking. Plus, the alloy is known for its good weldability, making it ideal for a wide array of industrial, structural, and decorative applications where a lightweight, corrosion-resistant material is essential.
Standards : ASTM B209 / ASME SB209
Temper : O,H14,H16,H18,H19,H22,H24
Thickness : 0.1-4
Width : coil
Length : 100-1600
Surface : Bright, polished, hair line, brush, sand blast, embossed, etching, etc.
Finish :Mill, Customer specific finish
Aluminum Coil Coating : PVC Coated, Color Coated, Polyester, Fluorocarbon, polyurethane and epoxy coating
Type : Hot-Rolled (HR) / Cold-Rolled (CR) Coil
| European Standard | GERMANY | UNS | DIN,WNr |
| B57S | AI-Mg-1 | A95005 | – |
| Weight% | Al | Si | Fe | Cu | Mn | Cr | Mg | Zn | Others Each | Others Total |
| 5005 | Bal | 0.30 max | 0.70 max | 0.20 max | 0.20 max | 0.10 max | 0.50 / 1.10 | 0.25 max | 0.05 max | 0.15 max |
| Material | Temper | Tensile Strength (N/mm²) | Yield Strength (N/mm²) | Elongation on 50mm (%) | |||
| 0.5 mm | 0.8 mm | 1.3 mm | 2.6mm | ||||
| 5005 | 0 | 95-145 | – | 18 | 20 | 21 | 22 |
| 5005 | H12 | 125-170 | 80 | 4 | 5 | 6 | 8 |
| 5005 | H14 | 145-185 | 100 | 3 | 3 | 5 | 6 |
| 5005 | H18 | 185 min | 165 | 1 | 2 | 3 | 3 |
Aluminium 5005 coils find extensive use in construction for roofing sheets, cladding panels, wall panels, and façades, thanks to their corrosion resistance and visual appeal. In the transportation sector, they are utilized for automotive parts, containers, and trailers. The marine industry depends on them for ship panels and offshore structures, while the fabrication industry employs them for machinery covers, tanks, and piping. They are also favored in signage, decorative applications, and interior design due to their excellent finishing properties.
Yes, we offer custom sizes for Aluminium 5005 Coils to meet specific project needs. Our team at Ram Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@ramaluminium.co.in
Aluminium 5005 Coils are widely used across various industries due to their excellent corrosion resistance, lightweight nature, and aesthetic appeal. In architecture, they are ideal for curtain walls, roofing, and cladding, offering durability and weather resistance. These coils are also popular in signage, anodized decorative finishes, and kitchen appliances for their smooth surface and adaptability to anodizing. Additionally, they are used in marine applications, automotive trims, and storage tanks, providing reliable performance in environments where strength and corrosion resistance are critical.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
