Welcome to Ram Aluminium, a trusted name in Kolkata’s industrial landscape. For years, we have built our reputation on a foundation of reliability and quality, specialising in the supply of high-grade aluminium products. Our Aluminium 5754 Angles are a prime example of this commitment, offering a perfect blend of strength and durability for the diverse needs of modern engineering and construction projects across India. We take pride in providing materials that professionals can depend on, ensuring their work stands the test of time.
The composition of Aluminium 5754 Angles is what sets them apart, being part of the magnesium-containing 5xxx series. This specific alloying gives the angles exceptional resistance to corrosion, especially in marine or chemical environments, making them a remarkably robust choice. They offer a great strength-to-weight ratio, are easily weldable, and maintain excellent formability, allowing them to be shaped and fabricated without losing their inherent toughness. This combination of properties makes them a versatile and reliable material for demanding applications.
Standards : ASTM B221 / B211 ASME SB221 / SB211, EN573, EN485, AMS 4003, AMS 4102
Temper : O,H12,H14,H16,H18,H19,H22,H24
Standard : ASTM, ASME, AMS, GB/T, JIS
Thickness : 50 mm to 6000 mm Long
Size : 3mm* 20mm* 20mm~ 12mm* 100mm* 100mm
Length : 1 To 6 Meters, Custom Cut Length
Finish : Mill, Customer specific finish
Surface : Anodize, powder coating, electrophoresis, PVDF coating, wood grain painting, matted, etc
| Mg | Mn | Si | Cu | Fe | Cr | Zn | Ti | Cu | Other (Each) | Others (Total) | Al |
| 2.60 – 3.60 | 0.0 – 0.50 | 0.0 – 0.40 | 0.0 – 0.40 | 0.0 – 0.30 | 0.0 – 0.20 | 0.0 – 0.15 | 0.0 – 0.10 | 0.0 – 0.05 | 0.0 – 0.05 | 0.0 – 0.15 | Balance |
| Proof Stress | Tensile Strength | Elongation at 50 mm | Hardness Brinell |
| 80 Min MPa | 190 – 260MPa | 12 Min % | 52 HB |
| UNS | EN | DIN | ISO | USA | WNR |
| A95754 | EN AW-5754 | AlMg3 | AlMg3 | AA5754 | 3.3535 |
Ram Aluminium based in Kolkata, India is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
Yes, we offer custom sizes for Aluminium 5754 Angles to meet specific project needs. Our team at Ram Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@ramaluminium.co.in
You’ll find Aluminium 5754 Angles hard at work in numerous critical applications. They are a fundamental component in shipbuilding and offshore structures, where their saltwater resistance is invaluable. The transportation industry relies on them for designing lightweight yet strong frameworks for trucks, trailers, and railcars. In architecture, they are used for sturdy but elegant structural supports, walkways, and decorative trims. Furthermore, their durability makes them ideal for a range of industrial uses, including the construction of heavy-duty platforms, storage systems, and machinery frames where longevity is paramount.
