Ram Aluminum is a leading manufacturer and supplier based in Kolkata, India, specializing in quality aluminum products. Committed to accuracy and excellence, they offer a wide range of aluminum solutions designed to meet industrial needs. One of their key products is Aluminium 3003 Channel, which is known for its superior hardness, durability and excellent corrosion resistance. The 3003 alloy is ideal for use in the manufacturing, construction and construction industry. Ram Aluminum ensures that all products, including the 3003 process, are manufactured to the highest standards, providing reliable and cost-effective solutions for projects.
Aluminium 3003 Channel is an aluminium-manganese alloy, with manganese being the main alloying element, typically comprising about 1.0–1.5%. It also includes trace amounts of copper, silicon, iron, and zinc, with aluminium making up the remainder. This blend enhances strength compared to pure aluminium while maintaining excellent corrosion resistance. In terms of mechanical properties, Aluminium 3003 boasts moderate tensile strength, good yield strength, and remarkable ductility. Although it isn’t heat-treatable, it responds well to cold working, offering good formability, weldability, and machinability for various structural and fabrication applications.
Specifications: ASTM B211 / ASME SB211
Temper: O, H12, H14, H16, H18, H22, H24, H26, H32, H112
Thickness: 0.91mm to 10 mm
Length: 10 to 12 Feet or as per clients’ requirement
Width: 9.5 mm X 9.5 mm To 150 mm X 75 mm or Custom
Finish: Mill, Customer specific finish
Surface: Anodize, powder coating, electrophoresis, PVDF coating, wood grain painting, matted, etc
Form: C-Channel, Box-Channel, U-Channel, J-Channel, Hat Channel, Strut Channels, Miscellaneous Channels
| Al | Cr | Cu | Fe | Mg | Mn | Other Total | Si | Ti | Zn |
| Remainder | – | 0.05 to 0.20% | 0.7% | – | 1.0 to 1.5% | 0.15% | 0.6% | – | 0.10% |
| Properties | Metric | Imperial |
| Tensile strength | 130 MPa | 18855 psi |
| Yield strength | 125 MPa | 18130 psi |
| Shear strength | 83 MPa | 12039 psi |
| Fatigue strength | 55 MPa | 7977 psi |
| Elastic modulus | 70-80 GPa | 10153-11603 ksi |
| Poisson’s ratio | 0.33 | 0.33 |
| Elongation | 10% | 10% |
| Hardness | 35 | 35 |
Ram Aluminium based in Kolkata, India is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
| European Standard | OLD | WNr | UNS | ISO | USA (AA) | GERMANY (DIN) |
| AW-AlCu4Mg1 | AU4G1 | 3.0517 | A93003 | AlCu4Mg | 3003 | AlCuMg2 |
Yes, we offer custom sizes for Aluminium 3003 Channel to meet specific project needs. Our team at Ram Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@ramaluminium.co.in
Aluminium 3003 Channels are commonly employed in applications that require a blend of strength, corrosion resistance, and ease of fabrication. They are frequently used in architectural frameworks, support structures, and interior fittings due to their sleek finish and lightweight characteristics. In industrial settings, these channels are utilized for constructing frames, brackets, and enclosures. They also have applications in transportation, signage, shelving systems, and more.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
