Welcome to Ram Aluminium, a trusted name in Kolkata’s industrial landscape. We take pride in being your reliable source for high-quality aluminium products, including our expertly crafted Aluminium 1050 Pipes. Our dedication lies in delivering materials that combine exceptional performance with value, ensuring your projects are built on a foundation of strength and durability. We understand the needs of local industries and are committed to supporting your growth with products you can depend on.
The composition of Aluminium 1050 is notable for its high purity, containing a minimum of 99.5% aluminium. This gives the pipes excellent corrosion resistance and high electrical and thermal conductivity. Mechanically, they offer good formability and weldability, making them easy to work with. While they are a commercially pure grade with moderate strength, they provide a great balance of workability and durability for many applications where maximum strength is not the primary concern.
Standards : ASTM B345, B241, B429 / ASME SB345, SB241, SB429
Temper : H14
Standard : AMS QQ-A-200/8, AMS QQ-A-200/9, AMS 4160/4161/4172
Size : 8 (1-1/2″ / 1.900″)
Outer Diameter : 1″ through 16″
Length : Double Random, Single Random, Cut Length
Thickness : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
End : Plain End, Beveled End, Threaded
| Alloy (ISS) | Equivalent alloy (A.A) | Copper | Magnesium | Silicon | Iron | Managanese Others* (Total) | Remarks | ||||||||||
| Old | New | U.S.A | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Max | Max. | Aluminum 99.0% Min. | ||||
| 1 B | 19500 | 1050 | — | 0.05 | — | — | — | 0.30 | 0.4 | — | 0.05 | 0.1 | Aluminum 99.5% Min. | ||||
| Alloy | Temper | UTS (Mpa) | Yield Strength (Mpa) | Elongation (%) | ||
| Minimum | Maximum | Minimum | Maximum | A 50mm (Minimum) | ||
| EN AW-1050 A | F | 60 | – | 20 | – | 23 |
| O | 60 | 95 | 20 | – | 23 | |
| STANDARD | WERKSTOFF NR. | ISO | UNS |
| Aluminium 1050 | 3.0255 | Al99.5 | A91050 |
Ram Aluminium based in Kolkata, India is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
Yes, we offer custom sizes for Aluminium 1050 Pipes to meet specific project needs. Our team at Ram Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@ramaluminium.co.in
You’ll find Aluminium 1050 Pipes are incredibly versatile. They are commonly used for general engineering purposes, architectural applications, and in the fabrication of fluid transfer systems where corrosion resistance is key. Their excellent conductivity makes them ideal for electrical busbars and heat exchangers. You can also spot them in the chemical and food processing industries, as well as in dairy and brewing equipment, where their non-toxic nature and ease of cleaning are highly valued for maintaining strict hygiene standards.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
