Welcome to Ram Aluminium, a trusted name in Kolkata’s industrial landscape. As a dedicated manufacturer and supplier, we take pride in producing high-quality aluminium components that meet the demanding standards of various industries. Our specialisation in Aluminium 5083 Fittings is a testament to our commitment to durability and performance, providing robust solutions that you can rely on for even the most challenging projects right from the heart of India.
The strength of Aluminium 5083 lies in its unique composition, primarily alloyed with magnesium, which gives it exceptional resistance to seawater and industrial chemicals. This marine-grade alloy is known for its superb mechanical properties, offering high tensile strength and excellent fatigue resistance while remaining easy to weld and work with. It maintains its toughness even in low-temperature environments, making it an incredibly versatile and reliable material for critical applications.
Standards : ASTM B361, B361
Dimensions : ASME/ANSI B16.9, ASME B16.28, MSS-SP-43
Size : 1/8” NB TO 48” NB. (Seamless & 100% X-Ray Welded, Fabricated)
Bending Radius : R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
Thickness : Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS
| UNS | USA | Canada | French | ISO |
| A95083 | 5083 | D54S | ND 5083 | Al-Mg-5 |
| Alloy | Fe | Si | Mg | Mn | Cu | Zn | Ti | Al |
| 5083 | 0.4 | 0.4 | 4.0-4.9 | 0.4-1.0 | 0.1 | 0.25 | 0.15 | Bal |
|---|
| Proof Stress | Tensile Strength | Hardness Brinell | Elongation |
| 125 Min MPa | 275 – 350 MPa | 75 HB | 12 Min % |
Ram Aluminium based in Kolkata, India is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
Yes, we offer custom sizes for Aluminium 5083 Fittings to meet specific project needs. Our team at Ram Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@ramaluminium.co.in
You’ll find Aluminium 5083 Fittings are indispensable in shipbuilding and offshore platforms, where their corrosion resistance is crucial. They are also widely used in the construction of pressure vessels, railway wagons, and chemical tankers. Beyond heavy industry, these fittings are perfect for architectural applications requiring both strength and a modern aesthetic, as well as in the automotive and aerospace sectors for constructing durable, lightweight frames and structures that must withstand harsh conditions.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
