Ram Aluminium stands out as a reliable manufacturer and supplier of Aluminium 1050 Forgings right in Kolkata, India. They specialize in delivering high-purity forged components tailored for electrical, engineering, and industrial needs. With state-of-the-art forging facilities, meticulous heat treatment processes, and rigorous quality checks, the company guarantees exceptional dimensional accuracy, a refined grain structure, and a top-notch surface finish. Ram Aluminium is equipped to handle bulk production, custom forging designs, and prompt nationwide delivery. Renowned for its excellent conductivity, corrosion resistance, and lightweight strength, their Aluminium 1050 Forgings ensure dependable performance in both light-duty and precision-engineered industrial settings.
Aluminium 1050 Forgings are crafted from commercially pure aluminium, boasting around 99.5% aluminium content. This impressive purity translates to outstanding corrosion resistance, superior electrical and thermal conductivity, and excellent ductility. The material is lightweight, provides moderate tensile strength, and allows for high elongation, making it ideal for precision forging, machining, and welding tasks. The forging process enhances internal grain flow, boosting structural integrity and dimensional stability. Aluminium 1050 consistently exhibits reliable mechanical behavior under low to moderate loads, performing well even in temperature-sensitive environments.
Standards : ASTM B247, B247
Temper : H14
Specification : DIN, ASTM, BS and all International Standards
Flat bar blocks : up to 27″ width and 15,000 lbs.
Cylinders and sleeves : up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs : up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings : up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts : up to 144″ maximum length and 20,000 lbs.
| European Standard | BS (OLD) | USA (AA) | GERMANY (DIN) | ISO | IS | Canadian |
|---|---|---|---|---|---|---|
| EN AW-1050 A | 1E | 1050 | Al99.5 | Al99.5 | 19500, 19501 | 1 S |
| Alloy (ISS) | Equivalent alloy (A.A) | Copper | Magnesium | Silicon | Iron | Managanese Others* (Total) | Remarks | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Old | New | U.S.A | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. | Max | Max. | Aluminum 99.0% Min. | ||
| 1 B | 19500 | 1050 | — | 0.05 | — | — | — | 0.30 | 0.4 | — | 0.05 | 0.1 | Aluminum 99.5% Min. | ||
| Alloy | Temper | UTS (Mpa) | Yield Strength (Mpa) | Elongation (%) | ||
|---|---|---|---|---|---|---|
| Minimum | Maximum | Minimum | Maximum | A 50mm (Minimum) | ||
| EN AW-1050 A | F | 60 | – | 20 | – | 23 |
| O | 60 | 95 | 20 | – | 23 | |
Ram Aluminium based in Kolkata, India is a renowned manufacturer and supplier of premium aluminium products, including Aluminium Bars, Sheets and Plates, Coils, Chequered Plates, Wires, Pipes, Fittings, Flanges, Forging, Circle, Angles. With a commitment to delivering exceptional quality and service, we cater to diverse industries, offering reliable solutions tailored to specific requirements. Our products are known for their superior strength, corrosion resistance, and precise dimensions. We focus on customer satisfaction by providing an extensive range of aluminium bars designed for structural, industrial, and decorative applications.
Yes, we offer custom sizes for Aluminium 1050 Forgings to meet specific project needs. Our team at Ram Aluminium is committed to providing customized solutions for all your requirements. For more details, contact us at sales@ramaluminium.co.in
Aluminium 1050 Forgings find their place in a variety of applications where high conductivity, corrosion resistance, and lightweight performance are crucial. They’re frequently utilized in electrical connectors, busbar joints, transformer components, and earthing hardware. In the realms of engineering and industrial fabrication, you’ll see them in couplings, flanges, hubs, shafts, and custom machined parts. These forgings also play a vital role in chemical, food processing, and pharmaceutical equipment, showcasing their versatility and reliability across different sectors.
